Roller presses especially for the chemical and mineral industry.

Kompaktor ARC MS

The specialist for customer-specific special solutions

Kompaktors from the ARC MS series compress powder to flakes or briquettes.

This process is described as dry compaction or briquetting.

The rollers of this Kompaktor are of a middle shaft design which makes the machines very robust and durable.

The machine series ranges from smaller machine with 300 mm roller diameter to machines with up to 1.100 mm roller diameter and throughputs of up to 120 t/h– for mineral applications.

Minerals/Metals:

  • Dedusting by briquetting
  • Granulate production, e.g. fertilizer

Chemicals:

  • Improve flowing properties and storage life of powders
  • Increase bulk weight
  • Improve flowing behaviour of powders

  • Roller diameter: 300 mm - 1,100 mm
  • Working width of 80 - 1,000 mm
  • Drive unit of 11 kW to 800 kW
  • Gravity fed
  • Vertical screw feeding for optimal throughput capacity
  • Throughput capacity of 0.5 – 120 t/h
  • Wear-protected construction
  • Segmented rollers, solid rollers or roll tyres
  • Vacuum de-aeration in the case of light products
  • Stainless steel construction optional
  • Gas-tight housing
  • Roller cooling optional
Kompaktor ARC MS MS 36 MS 60 MS 85 MS 180 MS 300
Press force (kN) 360 600 850 1800 3000
Roller diameter (mm) 300 400 520 520 712
Throughput in t/h 0,5 - 1,2 0,8 - 5 2 - 8 5 - 15 8 - 30
The throughput is dependent on the product.

Kompaktor ARC CS

Maintenance-friendly and robust

With the Kompaktor ARC CS 25 powder is process to granulate or briquettes. This process is described as compaction or briquetting.

Due to the cantilever bearing the Kompaktor ARC CS 25 is particularly easy to maintain and this with 25 tonnes of press force!

The Kompaktor ARC CS 25 is also suited for the laboratory and for small product amounts. It is made for frequent product changes and abrasive products because the rollers can be easily replaced.

  • for compaction, granulation and briquetting
  • for abrasive products
  • for frequent product changes
  • for laboratory applications in the mineral and chemical industry

  • Throughput up to 500 kg/h
  • Total press force 25 t
  • Roller diameter 228 mm
  • Vacuum de-aeration optional
  • Wear-protected construction optional
  • Different feeder auger screw systems
  • Hydraulics for working gap setting
  • Cantilever roller arrangement
  • Roller cooling optional
  • Special materials optional
Kompaktor ARC CS CS 25
Permissible total press force (t) 25
Press force (kN) 250
Roller diameter (mm) 228
Roller width (mm) 64 - 80
Throughput in kg/h 200 - 500
The throughput is dependent on the product.
